PWRD84 Radar Level Meter
Application:Measurement of liquid level storage tanks in petroleum, chemical, smelting, and other industries; measurement of material level solid storage tanks in industries such as steel, electric power, coal, and building materials.
Range:10m/20m/35m/85m/120m
Accuracy: ±1mm
Process connection:Thread/flflange
Process temperature: -40~315℃
Process pressure: -0.1~4.0Mpa
Frequency: 80GHz
Signal output:
4~20mA/HART 24V DC 2-wire /4-wire system;
4~20mA/HART 220V AC 4-wire system；
RS485/Modbus
Bluetooth function: Yes/no
Explosion-proof grade: Exia IIC T6 Ga；Exd IIC T6 Gb
Protection class: IP68
